The procedure for replacing the candle with the 3.2-litre engine of the Chevrolet Captiva is as follows:
(1) Remove the air duct and top of the air filter.
2) Remove the throttle.
3) Scrolling the brackets from the intake manifold.
4) Disconnect the slots to the left of the collector and tube on the right.
(5) Unlocking the 6 bolts, removing the manifold.
6) remove each coil and lace the candles using a candle-key "on 16" with a length of about 200 mm.
7) Gather everything in reverse sequence. When the pipe is installed in the manifold, the leakproofness of the compaction rings must be assured. If necessary, replace.
